Stainless Steel Rope Wire Anti Theft Mesh Luggage Security Bags Protector

Stainless Steel Rope Wire Anti Theft Mesh Luggage Security Bags Protector

  • Stainless Steel Rope Wire Anti Theft Mesh Luggage Security Bags Protector
  • Stainless Steel Rope Wire Anti Theft Mesh Luggage Security Bags Protector
  • Stainless Steel Rope Wire Anti Theft Mesh Luggage Security Bags Protector
Stainless Steel Rope Wire Anti Theft Mesh Luggage Security Bags Protector
Product Details:
Place of Origin: Hebei,China
Brand Name: Yuntong
Certification: CE Certificate,SGS
Model Number: YT-1612
Payment & Shipping Terms:
Minimum Order Quantity: 1 pieces
Packaging Details: Plastic foam and carton box for inner packing,Fumigated wooden cases for outer packing.
Delivery Time: Within 2 weeks after detail confirms
Payment Terms: T/T, , Western Union, Papal
Supply Ability: 1000000 square meters per year
Contact Now
Detailed Product Description
Name: Backpack Security Mesh Wire Diameter: 1.2mm-3.2mm
Mesh Aperture: 25x25-200x200mm Cable Structure: 1*7,7*7,7*19,1*19
Usage: Aviary Netting,animal Enclosure Feature: High Durability,temperature Tolerance,smooth Surface
Type: Woven Type And Ferrule Type Technique: By Hands
High Light:

backpack lock mesh

,

rucksack security mesh



Stainless Steel Rope Wire Mesh Luggage Security Bags Protector for Anti-theft







About Stainless Steel Rope Wire Mesh Luggage Security Bags Protector for Anti-theft:



Materials:304,304L,316,316L stainless steel wire rope
Wire rope structure:7*7 and 7*19 high-quality stainless steel wire rope
Rope(mm):1.0, 1.2, 1.5, 1.8, 2.0, 2.4, 2.5, 2.8, 3.0, 3.2,
Mesh:2.5*2.5, 3*3, 3.8*3.8, 4*4, 4.5*4.5, 5*5, 5.5*5.5, 6*6, 7*7, 7.6*7.6, 8*8, 10*10, 15*15, 30*30 etc. customized



Mesh Types of Stainless Steel Rope Wire Mesh Luggage Security Bags Protector for Anti-theft:



  • The knotted mesh is a kind of plain weave, each warp wire rope crosses alternately above and below each weft wire rope, warp and weft wire ropes generally have the same diameter.
  • The ferruled mesh is of the same physical properties with the knotted mesh, the only difference is in the combination style, the stainless wire rope is combined by the ferrules which are made of the same grade stainless steel.

Stainless Steel Rope Wire Anti Theft Mesh Luggage Security Bags Protector 0

Usage of Stainless Steel Rope Wire Mesh Luggage Security Bags Protector for Anti-theft:

Our stainless steel mesh is an extremely strong containment netting suitable for smaller mammals, primates and large birds. Individual mesh knots are double fastened and the netting does not have to be installed under tension.

YT-Stainless Steel Rope Wire Mesh Luggage Security Bags Protector
Model Wire Diameter Mesh Opening Normal Break
  inch mm inch mm 1bs.
YT-1220 3/64 1.2 4/5 x 4/5 20 x 20 270
YT-1225 3/64 1.2 1x1 25.4 x 25.4 270
YT-1230 3/64 1.2 1.2 x 1.2 30 x 30 270
YT-1238 3/64 1.2 3/2 x 3/2 38 x 38 270
YT-1625 1/16 1.6 1 x 1 25.4 x 25.4 480
YT-1630 1/16 1.6 1.2 x 1.2 30 x 30 480
YT-1638 1/16 1.6 3/2 x 3/2 38 x 38 480
YT-1650 1/16 1.6 2 x 2 51 x 51 480
YT-1676 1/16 1.6 3 x 3 76 x 76 480
YT-2038 5/64 2.0 3/2 x 3/2 38 x 38 676
YT-2050 5/64 2.0 2 x 2 51 x 51 676
YT-2060 5/64 2.0 2.4 x 2.4 60 x 60 676
YT-2076 5/64 2.0 3 x 3 76 x 76 676
YT-2450 3/32 2.4 2 x 2 51 x 51 920
YT-2460 3/32 2.4 2.4 x 2.4 60 x 60 920
YT-2476 3/32 2.4 3 x 3 76 x 76 920
YT-2490 3/32 2.4 3.55 x 3.55 90 x 90 920
YT-2410 3/32 2.4 4 x 4 102 x 102 920
YT-3250 1/8 3.2 2 x 2 51 x 51 1600
YT-3276 1/8 3.2 3 x 3 76 x 76 1600
YT-3290 1/8 3.2 3.55 x 3.55 90 x 90 1600
YT-3210 1/8 3.2 4 x 4 102 x 102 1600
YT-3212 1/8 3.2 4.75 x 4.75 120 x 120 1600



Service of Yuntong:

Yuntong is experienced in manufacturing high quality flexible rope mesh,providing different wire rope diameter,mesh width process,the nets shapes can be finished at square panel,rhombus panel,triangular panel. customized nets height and length.supplied more than 30 types border design plans to meet different installation required.

Stainless Steel Rope Wire Anti Theft Mesh Luggage Security Bags Protector 1
